Hangzhou Bright Roj Hmab Yas Khoom Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov neeg muag khoom ntawm kev cai roj hmab mount rau tsheb hauv Suav teb. Yog tias koj yuav mus yuav kev cai roj hmab mount rau tsheb ua nyob rau hauv Suav teb, txais tos kom tau txais cov ntaub ntawv ntau ntxiv los ntawm peb lub hoobkas. Peb kuj txais customized txiav txim.
Kev piav qhia
|
Lub npe |
Customized Rubber Mount rau Automotive |
|
Khoom siv |
Silicone, EPDM, NR, NBR, FKM, SBR, HNBR, IIR, CR FFKM thiab lwm yam |
|
Hardness |
20-85 Ntug A, ± 5 Ntug A |
|
Kub |
-40℃rau +300 degree |
|
Loj |
Raws li daim duab lossis qauv |
|
Xim |
Raws li koj xav tau (Panton xim daim npav) |
|
Daim ntawv thov |
Automotive, industrial, machinery, tub rog, hluav taws xob, kev kho mob, tsev neeg thiab lwm yam |
|
Kev ua tau zoo |
Zoo sealing & damping; |
|
Hom kev tsim khoom |
Compression, txhaj tshuaj, txhaj tshuaj hloov mus, extrusion, silicone kua txhaj tshuaj |
|
Ntau lawm |
Cov tshuab suav nrog 150T, 200T, 250T, 300T thiab 500T |
|
Cov cuab yeej ntsuas |
Vulcanization tester, tensile tester, roj hmab durometer, rwb thaiv tsev kuj tester thiab lwm yam |
|
Roj Hmab Compound |
tuaj yeem yog FDA, RoHs lossis REACH pom zoo, thiab cov ntawv xeem dawb thiab cov khoom siv tawv tawv tuaj yeem muab rau |
|
Pob |
Lub hnab yas sab hauv / sab nraum lub thawv / ntoo pallets / lossis lwm yam tshwj xeeb |
|
Sau ntawv |
Cov qauv thiab lub logo tuaj yeem ua raws li koj xav tau; |
PRODUCTION SHOW
Daim ntawv thov -Tshwj xeeb Compound Formulation
Automotive roj hmab mounts ua hauj lwm nyob rau hauv ntau yam ib puag ncig, xws li los ntawm siab -kub cav bays mus rau ya raws- raug undercarriage qhov chaw. Peb tsis siv ib qho roj hmab universal rau txhua daim ntawv thov. Peb pab pawg engineering xaiv elastomers raws li cov kev ua haujlwm tshwj xeeb ntawm lub mount.
Rau kev ncua sij hawm thiab lub cev nce, cov roj hmab ntuj (NR) thiab styrene -butadiene roj hmab (SBR) feem ntau yog siv vim lawv qaug zog tsis kam thiab muaj peev xwm thauj khoom. Rau lub cav thiab kis tau tus mob mounts raug kub thiab roj pos huab, peb siv ethylene propylene diene monomer (EPDM) los yog nitrile roj hmab (NBR). Cov txheej txheem sib xyaw suav nrog cov qib tshwj xeeb ntawm cov pa roj carbon dub, cov roj ua haujlwm, thiab cov tshuaj tua kab mob kom ua tiav lub hom phiaj durometer thiab cov khoom siv kho tshuab. Txhua qhov sib xyaw tshiab tau dhau los ntawm kev tshuaj xyuas rheometer los tsim kev kho kom zoo dua qub ua ntej pib tsim khoom.
Moulding thiab Vulcanization Control
Peb siv ob qho tib si compression thiab hloov molding txheej txheem nyob ntawm qhov nyuaj ntawm mount geometry. Hloov molding feem ntau yog nyiam rau mounts nrog intricate cov kab noj hniav los yog ntau yam hlau inserts, raws li nws muab cov khoom zoo dua ntws thiab txo cov voids.
Vulcanization yog lub sijhawm -kub- kev ua haujlwm siab. Peb cov molding presses yog nruab nrog cov programmable logic controllers (PLCs) uas tswj xyuas cov voj voog tsis sib xws. Rau siab - ntim ntau lawm, peb siv cov tshuab demolding tshuab los txo cov kev puas tsuaj. Cov pwm yog tsim los ntawm cov cuab yeej hardened steel nrog cov qauv tsim nyog thiab cov kab sib cais tsim kom txo qis qis thiab ua kom muaj qhov sib xws.
Roj hmab-rau-Hlau Bonding Technology
Ntau lub tsheb roj hmab mounts xav tau cov hlau ntxig rau cov qauv txuas. Lub durability ntawm cov khoom no nyob ntawm tag nrho ntawm kev ncaj ncees ntawm cov roj hmab-rau- hlau daim ntawv cog lus. Peb siv ntau - cov txheej txheem sib txuas:
Kev npaj nto:Hlau inserts undergo txhaj blasting los yog tshuaj etching los tsim ib tug micro-roughened nto profile.
Daim ntawv thov Primer:Ib qho corrosion-inhibiting primer yog siv thiab ci los ua ib txheej txheej.
Adhesive Txheej:Ib qho tshwj xeeb sib txuas nplaum yog siv rau ntawm primer. Cov nplaum no yog tsim los rau co-vulcanize nrog roj hmab compound thaum lub voj voog molding.
Ntxig Loading:Inserts yog muab tso rau hauv pwm siv precision fixtures los xyuas kom meej kev sib raug zoo.
Lub zog ntawm daim ntawv cog lus tau txheeb xyuas los ntawm cov qauv txheej txheem tev thiab txiav txiav. Ib qho kev sib raug zoo mount yuav tsum tsis sib haum xeeb hauv cov roj hmab es tsis yog ntawm cov nplaum sib txuas.
Dimensional Accuracy thiab Tooling
Custom automotive mounts yuav tsum sib cuam tshuam nrog cov qauv tsheb uas twb muaj lawm. Peb tuav nruj me ntsis kam rau ua rau cov yam ntxwv tseem ceeb xws li ntsia liaj qhov rooj qhov chaw, bore diameters, thiab tag nrho lub hnab ntawv qhov ntev. Tooling yog tsim los nrog kev them nyiaj rau cov roj hmab shrinkage, uas txawv los ntawm kev sib xyaw thiab geometry.
Rau kev nthuav qhia cov khoom tshiab, peb tsim thawj -cov qauv qauv rau cov neeg siv khoom siv tau. Kev tshuaj xyuas qhov ntev yog ua los ntawm kev sib koom ua ke ntsuas tshuab (CMM) thiab cov khoom sib piv kho qhov muag. Txhua qhov sib txawv ntawm cov lus qhia tshwj xeeb yog hais los ntawm kev hloov kho cov cuab yeej ua ntej tso tawm tag nrho.
Kev xeem thiab validation
Peb ua qhov kev sim niaj hnub los xyuas kom meej tias cov khoom tsim tau raws li cov qauv tsim. Standard xeem muaj xws li:
Tensile thiab Tear Strength:Txheeb xyuas qhov tseeb ntawm cov khoom siv hauv paus.
Compression Set:Ntsuas cov khoom muaj peev xwm rov qab tau tom qab lub sijhawm ntev compression.
Kev kuaj Hardness:Pom zoo durometer sib xws nyob rau hauv ntau lawm batch.
Dynamic Stiffness Testing:Ntsuas lub mount qhov kev ua tau zoo nyob rau hauv oscillating loads ntawm cov frequencies thiab amplitudes.
Environmental Aging:Txheeb xyuas cov khoom khaws cia tom qab raug tshav kub, ozone, thiab dej immersion.
Cov qhabnias xeem tau muab tso ua ke rau hauv cov ntaub ntawv tshuaj xyuas uas nrog cov khoom xa tuaj. Peb tsis ua lub tsheb - qib validation nyob rau hauv - tsev tab sis tsim peb cov txheej txheem xeem kom muaj kev cuam tshuam nrog kev lag luam - qauv tsheb specifications.
RUBBER PRODUCTS FOR CAR SIV
Kev tsim khoom yooj yim thiab cov ntaub ntawv
Peb lub chaw txhawb nqa cov khoom ntim ntau los ntawm cov qauv qauv mus rau siab - ntim OEM khoom. Tooling peev thiab qhov tsawg kawg nkaus txiav txim kom muaj nuj nqis yog tsim kom haum rau ob qho tib si theem kev loj hlob thiab series ntau lawm.
Peb muab cov ntaub ntawv nthuav dav suav nrog cov ntaub ntawv cov ntaub ntawv, cov phiaj xwm tswj cov txheej txheem, thiab cov ntaub ntawv tshuaj xyuas qhov ntev. Rau cov neeg siv khoom xav tau kev taug qab ntxiv, peb khaws ntau ntau -cov ntaub ntawv qib sib txuas cov khoom siv raw khoom mus rau kev tsim khoom thiab cov txiaj ntsig kev xeem.
Kev cai automotive roj hmab mounts xav tau kev qhuab ntuas kev tsim khoom thiab kev paub txog cov khoom siv. Peb qhov chaw yog tsim los xa cov khoom uas ua tau raws li qhov xav tau ntawm engineering nrog qhov zoo ib yam. Peb tsom rau cov txheej txheem kev ntseeg siab thiab kev ua haujlwm raug hauv peb cov haujlwm tsim khoom.
